Ball valve, 1/2″ NPT-M X 1/2″ NPT-F, 316 stainless steel

Technical specifications

Brand: Parker

Series Details

Parker B-Series two-way manual, pneumatic, and electric ball valves provide quick quarter-turn on/off control of fluids used in process and instrumentation applications. A wide selection of valve bodies, seats, and seal materials offers a broad range of pressures and temperatures for use. Features: Floating ball design provides seat wear compensation. Available in 316 stainless steel and brass. Monel 400 alloy and Hastelloy C-276 construction available upon request. Micro-finished ball provides positive sealing. Direct flow path for minimal pressure drop. Bidirectional flow. Wide variety of common US and SI ports. 90° actuation. Panel mountable. Adjustable PTFE stem seal can be kept in line. Handle indicates flow direction. Low operating torques. Positive handle stops. Color-coded handles. Pneumatic and electric actuation options available. Optional tensioned PTFE stem seals. Optional non-adjustable O-ring stem seals. Optional upstream and downstream drain designs. Optional stainless steel and extended handles.

Features

• Body material:  SSP – 316 stainless steel
• Orifice:  8M – 1/2″ male NPT | 8F – 1/2″ female NPT
• Seal material:  White – PTFE
• Valve series:  B8L
• CV of flow data:  6.42
• Flow data orifice size:  0.406
• Flow data orifice mm:  10.3
• XT flow rate data:  0.37
• Dimensions B inches (mm):  2.22 (56.4) | 2.15 (54.6)
• Dimensions A Inches (mm):  2.22 (56.4)|2.15 (54.6)
• Dimensions C inches (mm):  0.69 (17.5)
• Dimensions D inches (mm):  0.70 (17.8)
• Dimensions E Inches (mm):  1.74 (44.2)
• Dimensions G Inches (mm):  4.00 (101.6)
• Dimensions H inches (mm):  0.90 (22.9)
• Dimensions F inches (mm):  1.50 (38.1)
• Colored lever handles:  Black = Standard
• Nominal CWP pressures:  6000 psig (414 bar)*
• Nominal pressures with PTFE seats:  1500 psig (103 bar)
• Dimensions in inches (mm):  0.38 (9.7)
• Seat material:  J2 – PCTFE
