Description
Technical specifications
Brand: Parker
- Hose sheath type: Standard
- DI flexible (dimension): -10
- FluideMédia: Hydraulic Fluids, Air, Water, Petroleum and water-glycol based fluids, lubricating oils, Petroleum and water-glycol based fluids, lubricating oils, air and water
- Brand: Parker
- Division:Polymer Hose Division Europe
- Sector: General Industrial, Off-road Machinery
- Application: Demanding medium pressure hydraulic applications
- Technology: Fluid & Gas Handling
- Product type: Hydraulic hose
- Product Style: Elite No-Skive Compact
- Maximum working pressure: 2175 psi, 15 MPa, 150 bar
- Inner diameter of the flexible hose: 15.9 mm, 5/8 inch
- Outer diameter of the flexible hose: 22.2 mm, 0.874 inch
- Tube type: Nitrile (NBR)
- Minimum radius of curvature: 150 mm, 5.905 inch
- Cover material: Synthetic rubber
- Design factor: 4:1
- Cover color: Black
- Compatible fitting: 46 Series
- Maximum operating temperature: 100°C (Water: 85°C, Air: 70°C), 212°F (Water: 185°C, Air: 158°C)
- Minimum operating temperature: -40 °C
- Specifications met: EN 857 1SC – ISO 11237 Type 1SC
- Materials used: Rubber
- Inner tube material of the hose: Nitrile NBR
- Hose reinforcement material: One high-tensile steel wire braid
- Weight: 0.41 kg/m, 0.27 lb/ft
