Description
Technical specifications
Brand: Parker
- Hose sheath type: Standard
- DI flexible (dimension): -20
- Brand: Parker
- Division: Polymer Hose Division Europe
- Sector: Off-road Machinery, Transportation, Industrial Manufacturing Equipment
- Application: General medium pressure hydraulic applications
- Technology: Fluid & Gas Handling
- Product type: Hydraulic hose, Specialty hose
- Product Style: No-Skive
- Maximum operating pressure: 6.3 MPa, 900 psi, 63 bar
- Inner diameter of the flexible hose: 31.8 mm, 1-1/4 inch
- Hose outer diameter: 44.8 mm, 1.764 inches
- Minimum radius of curvature: 420 mm, 16.535 inches
- Design factor: 4:1
- Cover color: Black
- Compatible fitting: Parkrimp Fitting 48 Series
- Maximum operating temperature: 100 (Water: 85, Air: 70) °C, 212 (Water: 185, Air: 158) °F
- Minimum operating temperature: -40 °C, -40 °F
- Specifications met: EN 853 1SN – ISO 1436 Type 1 – SAE 100R1AT
- Materials used: Rubber
- Cover material: Synthetic rubber
- Inner tube material of the hose: Nitrile NBR
- Hose reinforcement material: One high-tensile steel wire braid
- Weight: 1.19 kg/m, 0.80 lb/ft
- FluideMédia: Petroleum and water-glycol based fluids, lubricating oils, air and water, Hydraulic fluids
