Pressure gauge 0 – 25 bar, vertical radial G1/4 BSP connection, 63 mm dial, glycerin-filled stainless steel case

  Technical specifications

• Pressure gauge with pressure tube – Stainless steel series
• Type: 131.11
• Specifications according to datasheet: PM 01.05
• Case: stainless steel
• Movement: stainless steel
• Measuring element: 316L stainless steel
• Dial diameter: 63 mm
• Measuring range type: positive pressure
• Measuring range: 0 to 25 bar
• Process connection: G 1/4 B
• Connection position: vertical (radial)
• Sight glass: polycarbonate
• Accuracy class: Cl. 2.5
• Case type: standard
• Case surface: unfinished
• Protection rating: IP54
• Ambient temperature: -40 to +60 °C
• Packaging: standard packaging
• Standard: EN 837 (International Pressure Gauge Standard)
• Manufacturer: WIKA
• Marking: serial number on dial
• Dial stop: at zero
