Pressure gauge 0–40 bar, vertical radial G1/2 BSP connection, 100 mm dial, glycerin-filled stainless steel case

  Technical specifications

• Pressure gauge with pressure tube – Process Series
• Type: 233.50
• Specifications according to datasheet: PM 02.02
• Measuring element: stainless steel
• Liquid filling: with glycerin
• Dial diameter: 100 mm
• Measuring range: 0 to 40 bar
• Process connection: G 1/2 B
• Connection position: vertical (radial)
• Sight glass: safety glass
• Needle: standard
• Accuracy class: Cl. 1.0
• Overpressure capacity: standard
• Case material: 1.4301 stainless steel
• Case surface: unfinished
• Measuring element material: 316L stainless steel
• Filling liquid: glycerin
• Protection rating: IP65
• Fluid temperature: up to +100 °C
• Ambient temperature: -20 to +60 °C
• Movement: stainless steel
• Packaging: individual packaging
• Standard: EN 837
• Manufacturer: WIKA
