Multiport Valve, NPT-M X 1/2″ NPT-F, stainless steel 316

Technical specifications

Brand: Parker

• Body material: 316 Stainless Steel
• Options :N/A
• Compliant with certifications: N/A
• Operating pressure: 6000 PSI / 414 BAR
• Inlet port connection type: NPT Male
• Intake connection size: 1/2 Inch
• Outlet connection type: NPT Female x 3
• Outlet connection size: 1/2 Inch
• Mounting option: N/A
• Packaging material: PTFE
• Seat material: Metal to Metal
• Température de service :PTFE packing: From -54°C to +260°C, From -65°F to +500°F
  Graphite packing: From -54°C to +538°C, From -65°F to +1000°F
• Options supplémentaires :Contact Parker for the following options:
  Material Options: Alloy M400, Duplex, Super Duplex, Alloy C276, Titanium, Alloy 625, Alloy 825, Carbon Steel
  Connection options: BSPP, BSPT, Socket Weld, Inverted and PTFree connectTM
  Seat options: Regulating/Metering Tip, Stellite Tip, PCTFE Soft Tip, PEEK Soft Tip
  Operator options: Anti-tamper, Handwheel, T bar locking,
  Other Options: Panel Mount, Base Mount, Brackets, Oxygen clean, NACE compliance, Assembly and Test of Free Issue Instrument
• Flow coefficient: 0.35
• Opening size: 4 mm
• For the fluid type: General Gaseous and Liquid Media
• Product type: Valve gauge
